Design and validation of a portable, inexpensive and multi-beam timing light system using the Nintendo Wii hand controllers

Ross Clark; K Paterson; C Ritchie; S Blundell; A L Bryant

doi:10.1016/j.jsams.2010.12.001

Back

Design and validation of a portable, inexpensive and multi-beam timing light system using the Nintendo Wii hand controllers

Journal article

Peer reviewed

Design and validation of a portable, inexpensive and multi-beam timing light system using the Nintendo Wii hand controllers

Ross Clark, K Paterson, C Ritchie, S Blundell and A L Bryant

Journal of Science and Medicine in Sport, Vol.14(2), pp.177-182

2011

DOI: https://doi.org/10.1016/j.jsams.2010.12.001

Files and links (1)

url

https://doi.org/10.1016/j.jsams.2010.12.001View

Published Version

Abstract

run

sprint

speed

gait

athlete

talent identification

Objectives: Commercial timing light systems (CTLS) provide precise measurement of athletes running velocity, however they are often expensive and difficult to transport. In this study an inexpensive, wireless and portable timing light system was created using the infrared camera in Nintendo Wii hand controllers (NWHC). Design: System creation with gold-standard validation. Method: A Windows-based software program using NWHC to replicate a dual-beam timing gate was created. Firstly, data collected during 2. m walking and running trials were validated against a 3D kinematic system. Secondly, data recorded during 5. m running trials at various intensities from standing or flying starts were compared to a single beam CTLS and the independent and average scores of three handheld stopwatch (HS) operators. Intraclass correlation coefficient and Bland-Altman plots were used to assess validity. Absolute error quartiles and percentage of trials in absolute error threshold ranges were used to determine accuracy. Results: The NWHC system was valid when compared against the 3D kinematic system (ICC. = 0.99, median absolute error (MAR). = 2.95%). For the flying 5. m trials the NWHC system possessed excellent validity and precision (ICC. = 0.97, MAR < 3%) when compared with the CTLS. In contrast, the NWHC system and the HS values during standing start trials possessed only modest validity (ICC < 0.75) and accuracy (MAR > 8%). Conclusions: A NWHC timing light system is inexpensive, portable and valid for assessing running velocity. Errors in the 5. m standing start trials may have been due to erroneous event detection by either the commercial or NWHC-based timing light systems. © 2010 Sports Medicine Australia.

Details

Title: Design and validation of a portable, inexpensive and multi-beam timing light system using the Nintendo Wii hand controllers
Authors: Ross Clark (Author) - University of Melbourne
K Paterson (Author) - Australian Catholic University
C Ritchie (Author) - University of Melbourne
S Blundell (Author) - Australian Catholic University
A L Bryant (Author) - University of Melbourne
Publication details: Journal of Science and Medicine in Sport, Vol.14(2), pp.177-182
Publisher: Elsevier Australia
Date published: 2011
DOI: 10.1016/j.jsams.2010.12.001
ISSN: 1440-2440
Organisation Unit: University of the Sunshine Coast, Queensland; School of Health and Sport Sciences - Legacy; School of Health and Behavioural Sciences - Legacy; School of Health - Public Health
Language: English
Record Identifier: 99450551602621
Output Type: Journal article
