Residual Stress in Self-Piercing Riveting (SPR) Joints—A Review

Journal article

Open access

Peer reviewed

Residual Stress in Self-Piercing Riveting (SPR) Joints—A Review

Rezwanul Haque

Materials Performance and Characterization, Vol.7(4), pp.956-968

2018

DOI: https://doi.org/10.1520/MPC20170109

Files and links (2)

pdf

Residual Stress in Self-Piercing Riveting (SPR) Joints - A Review1,019.46 kBDownload View

Accepted Version Open Access

url

https://doi.org/10.1520/MPC20170109View

Published Version

Abstract

self-piercing riveting

residual stress

joining

rivet flaring

mechanical interlock

neutron diffraction

contour method

synchrotron diffraction

time of flight

Self-piercing riveting (SPR) is a high-speed method of joining sheet materials by creating a mechanical interlock between the sheets. Unlike conventional riveting, SPR does not require predrilling. Automobile industries adopted this joining technique because of its suitability in joining dissimilar materials and doing so at high-volume production. However, in SPR, the rivet plastically deforms and residual stress develops in the joint. The deformation behavior of the rivet and the residual stress distribution in SPR joints are poorly understood. This leads to difficulties in developing new product and optimizing the process. Development of new rivet and die geometries are also limited since the residual stress state in SPR joints are not fully described. Several key issues in modeling and measuring residual stress in SPR joints are discussed. How the plastically induced residual stress can be linked to the different phases of the riveting process is also described. This is an area of SPR with numerous prospects for research. It is expected that advancement will be achieved by a combination of techniques, including laboratory recreation, finite element modeling and manufacturing trials.

Details

Title: Residual Stress in Self-Piercing Riveting (SPR) Joints—A Review
Authors: Rezwanul Haque (Author) - University of the Sunshine Coast - Faculty of Science, Health, Education and Engineering
Publication details: Materials Performance and Characterization, Vol.7(4), pp.956-968
Publisher: A S T M International
Date published: 2018
DOI: 10.1520/MPC20170109
ISSN: 2379-1365
Copyright note: (c) 2018 the Authors. The author's accepted version is reproduced here in accordance with the publisher's copyright policy. The final definitive version is available here: https://doi.org/10.1520/MPC20170109
Organisation Unit: School of Science and Engineering - Legacy; University of the Sunshine Coast, Queensland; School of Science, Technology and Engineering
Language: English
Record Identifier: 99450626802621
Output Type: Journal article
