Journal article
Pore structure characterization of North American shale gas reservoirs using USANS/SANS, gas adsorption, and mercury intrusion
Fuel, Vol.103, pp.606-616
2013
Abstract
Small-angle and ultra-small-angle neutron scattering (SANS and USANS), low-pressure adsorption (N2 and CO2), and high-pressure mercury intrusion measurements were performed on a suite of North American shale reservoir samples providing the first ever comparison of all these techniques for characterizing the complex pore structure of shales. The techniques were used to gain insight into the nature of the pore structure including pore geometry, pore size distribution and accessible versus inaccessible porosity. Reservoir samples for analysis were taken from currently-active shale gas plays including the Barnett, Marcellus, Haynesville, Eagle Ford, Woodford, Muskwa, and Duvernay shales. Low-pressure adsorption revealed strong differences in BET surface area and pore volumes for the sample suite, consistent with variability in composition of the samples. The combination of CO2 and N 2 adsorption data allowed pore size distributions to be created for micro-meso-macroporosity up to a limit of ∼1000 Å. Pore size distributions are either uni- or multi-modal. The adsorption-derived pore size distributions for some samples are inconsistent with mercury intrusion data, likely owing to a combination of grain compression during high-pressure intrusion, and the fact that mercury intrusion yields information about pore throat rather than pore body distributions. SANS/USANS scattering data indicate a fractal geometry (power-law scattering) for a wide range of pore sizes and provide evidence that nanometer-scale spatial ordering occurs in lower mesopore-micropore range for some samples, which may be associated with inter-layer spacing in clay minerals. SANS/USANS pore radius distributions were converted to pore volume distributions for direct comparison with adsorption data. For the overlap region between the two methods, the agreement is quite good. Accessible porosity in the pore size (radius) range 5 nm-10 μm was determined for a Barnett shale sample using the contrast matching method with pressurized deuterated methane fluid. The results demonstrate that accessible porosity is pore-size dependent.
Details
- Title
- Pore structure characterization of North American shale gas reservoirs using USANS/SANS, gas adsorption, and mercury intrusion
- Authors
- C R Clarkson (Author) - St. Mary's UniversityN Solano (Author) - University of CalgaryR M Bustin (Author) - University of British ColumbiaA M M Bustin (Author) - University of British ColumbiaGareth R L Chalmers (Author) - University of British ColumbiaL He (Author) - Oak Ridge National LaboratoryY B Melnichenko (Author) - Oak Ridge National LaboratoryA P Radliński (Author) - Griffith UniversityT P Blach (Author) - Griffith University
- Publication details
- Fuel, Vol.103, pp.606-616
- Publisher
- Elsevier Ltd
- Date published
- 2013
- DOI
- 10.1016/j.fuel.2012.06.119
- ISSN
- 0016-2361; 1873-7153; 0016-2361
- Organisation Unit
- University of the Sunshine Coast, Queensland; School of Science, Technology and Engineering
- Language
- English
- Record Identifier
- 99513907702621
- Output Type
- Journal article
