Inter-batch and inter-feedstock variability of an acid modified bitumen
Journal article   Peer reviewed

Inter-batch and inter-feedstock variability of an acid modified bitumen

Gregory W White
Road Materials and Pavement Design, Vol.17(3), pp.658-677
2016
DOI: https://doi.org/10.1080/14680629.2015.1108220
url
https://doi.org/10.1080/14680629.2015.1108220View
Published Version

Abstract

bitumen variability M1000 polyphosphoric acid acid modified bitumen MSCR
Fourteen samples of an acid modified bitumen for asphalt manufacture (known as M1000) were tested according to Australia's national paving-grade bitumen specification and using Multiple Stress Creep Recovery (MSCR) protocols. Testing was conducted two, three and four years after manufacture. The 14 samples represented a number of batches of bitumen of identical type and grade manufactured over a six-month period. All batches were manufactured in Australia from imported feedstock (blends of refined crude oil). Six samples were manufactured from one feedstock and the remaining eight from a different feedstock. Inter-batch/intra-feedstock variability of compliance properties at the time of release was low (4-16%). For most of the test parameters (including viscosity, penetration and creep compliance), there were significant differences for the samples manufactured from the two different feedstocks (p-values .06-<.01). The difference between samples from different feedstocks was magnified by accelerated ageing and by pretest storage time. For example, the average 17% difference in viscosity after accelerated ageing measured at the time of release had increased to an average 82% difference four years later. It is recommended that the Australian specification be modified to protect consumers from unintended variability in performance resulting from unknown changes in imported feedstocks. The tests showed that the current bitumen specification's focus on viscosity is unable to discriminate between feedstocks, resulting in significant differences in bitumen ageing, stress sensitivity and high temperature (above 64°C) response to shear stress. The MSCR test is recommended as a performance-based assessment for bitumen response to shear stress at high temperature. © 2015 Taylor & Francis

Details

Metrics

8 File views/ downloads
502 Record Views
6 Times Cited - Web of Science

InCites Highlights

These are selected metrics from InCites Benchmarking & Analytics tool, related to this output

Web Of Science research areas
Construction & Building Technology
Engineering, Civil
Materials Science, Multidisciplinary
