Journal article
Geological evaluation of Halfway-Doig-Montney hybrid gas shale-tight gas reservoir, northeastern British Columbia
Marine and Petroleum Geology, Vol.38(1), pp.53-72
2012
Abstract
Evaluation of the reservoir quality of the Triassic Halfway-Montney-Doig hybrid gas shale/tight gas reservoir in the Groundbirch field in northeastern British Colombia requires an integration of unconventional and conventional methodologies. Reservoir evaluation includes reservoir thickness and structure, total porosity, TOC content, organic maturity, pore size distribution (micro- to macro-pore size fractions), surface area, mineralogy and pulse-decay permeability. Quartz (10-74%), carbonate (13-73%) and feldspar (0-42%) dominate the mineralogy of all formations with illite (0-32%) being locally important. The T max values range between 443 and 478 °C placing the reservoirs beyond the oil window. Pore size distribution by low-pressure gas adsorption analysis identifies a large variation between the contributions from the micro-, meso- and macro-pore size fractions. Matrix permeabilities range between 1.0E-3 and 6.5E-7 mD at an effective stress between 2400 and 3300 PSI (16.5-22.8 MPa).Changes in depositional environments and diagenetic processes manifest as differences in lithology and mineralogy within the Montney and Doig reservoirs which subsequently affect the fabric, texture and pore size distribution. Fabric, texture and pore size distribution contribute to the variation in the permeability and the proportions of free to sorbed gas within the reservoir. Quartz-rich, coarser-grained intervals (upper portions of Doig C, B and Halfway Formation) have lower surface area, greater porosities and a higher volume of macropores compared to the carbonate- and clay-rich finer-grained intervals (Doig A). Permeabilities do not vary according to lithology with higher permeabilities found within both fine-grained (Doig A) and coarser-grained (Halfway Formation) units. Permeability is controlled by pore size distribution. Higher permeability samples contain a balanced ratio between micro-, meso- and macro-porosity. The finer-grained intervals have higher sorbed gas capacity due to higher surface areas because of the higher volumes of finer mesopores and micropores than the coarser-grained units. However, porosity and permeability are low in some parts of the Doig A and fracture stimulation is necessary to achieve economic flow rates.
Details
- Title
- Geological evaluation of Halfway-Doig-Montney hybrid gas shale-tight gas reservoir, northeastern British Columbia
- Authors
- Gareth R L Chalmers (Author) - University of British ColumbiaR M Bustin (Author) - University of British Columbia
- Publication details
- Marine and Petroleum Geology, Vol.38(1), pp.53-72
- Publisher
- Elsevier Ltd
- Date published
- 2012
- DOI
- 10.1016/j.marpetgeo.2012.08.004
- ISSN
- 0264-8172; 1873-4073; 0264-8172
- Organisation Unit
- University of the Sunshine Coast, Queensland; School of Science, Technology and Engineering
- Language
- English
- Record Identifier
- 99513884402621
- Output Type
- Journal article
