Ability to predict flexural properties of Douglas-fir crossarms

Journal article

Peer reviewed

Ability to predict flexural properties of Douglas-fir crossarms

Christopher H Anderson, Arijit Sinha, Matthew J Konkler and Jeffrey J Morrell

Wood Material Science and Engineering, Vol.16(6), pp.366-374

2021

DOI: https://doi.org/10.1080/17480272.2020.1740783

Files and links (1)

url

https://doi.org/10.1080/17480272.2020.1740783View

Published Version

Abstract

crossarms

flexural properties

knots

Douglas-fir

MOR

MOE

Crossarms are heavy timbers used to support electrical lines on utility poles. The requirements for crossarm material are fairly strict especially with respect to limitations on the presence of knots, which represent a gap or hole in the timber and also result in grain deviations that can affect properties. The strict grading rules can sometimes result in shortages of acceptable material. The potential for accepting arms with minor, but currently unacceptable defects was explored on a population of 200 rejected Douglas-fir crossarms and 50 arms that met current standards. Knot diameter and location on the arms were mapped and the arms were tested to failure in a specially designed apparatus that simulated an actual line load. The resulting data were used to calculate Modulus of Rupture (MOR) and Modulus of Elasticity (MOE). Nearly all arms failed above the minimum American National Standards assumed MOR value of 53.78 MPa and many of the rejected arms had higher MOR values than acceptable arms. While there was more variability in properties for the rejected arm population, correlations between knot diameter or knot location and MOR were all exceeding poor (r2 ≤ 0.25). The results suggest the need for further evaluation of the emphasis on knots in grading rules.

Details

Title: Ability to predict flexural properties of Douglas-fir crossarms
Authors: Christopher H Anderson (Author) - Oregon State University
Arijit Sinha (Corresponding Author) - Oregon State University, United States
Matthew J Konkler (Author) - Oregon State University, United States
Jeffrey J Morrell (Author) - University of the Sunshine Coast
Publication details: Wood Material Science and Engineering, Vol.16(6), pp.366-374
Publisher: Taylor & Francis
Date published: 2021
DOI: 10.1080/17480272.2020.1740783
ISSN: 1748-0272; 1748-0280
Organisation Unit: University of the Sunshine Coast, Queensland; National Centre for Timber Durability and Design Life; Forest Research Institute
Language: English
Record Identifier: 99450833002621
Output Type: Journal article

Metrics

48 Record Views

2 Times Cited - Web of Science

InCites Highlights

These are selected metrics from InCites Benchmarking & Analytics tool, related to this output

Collaboration types: Domestic collaboration; International collaboration
Web Of Science research areas: Materials Science, Paper & Wood
