A simple but effective model for characterizing SPR joints in steel sheet

Rezwanul Haque, Neal S Williams, Stuart E Blacket and Yvonne Durandet

Journal of Materials Processing Technology, Vol.223, pp.225-231

2015

DOI: https://doi.org/10.1016/j.jmatprotec.2015.04.006

Files and links (2)

pdf

PDF - Author's Accepted Version (Open Access)915.85 kBDownload View

Accepted VersionPDF - Author Accepted Version (Open Access)CC BY-NC-ND V4.0, Open Access

url

https://doi.org/10.1016/j.jmatprotec.2015.04.006View

Published Version

Abstract

self-piercing riveting

joint quality

rivet flaring model

characteristic force-displacement curve

joining by forming, SPR

A simple and effective model has been developed to determine rivet flaring in selfpiercing riveted (SPR) joints. Both interrupted and un-interrupted SPR experiments were performed with recording of force and punch displacement data. Based on the analysis of experimental SPR process data and the examination of cross-sections of SPR samples, two key points of the force-displacement curves were identified that mark the start (d0) and end (dmax) of rivet flaring respectively. It was found that these two events were able to be related to the path of the tip of the flaring rivet and hence the internal characteristics of the SPR samples via a simplified geometric approach. A linear relationship between the rivet flaring and (dmax-d0) was thus established. The study shows that in the absence of a finite element model, the experimental characteristic force-displacement curve can be used directly to estimate the rivet flaring without having to cut the SPR joint.

Details

Title: A simple but effective model for characterizing SPR joints in steel sheet
Authors: Rezwanul Haque (Author) - Swinburne University of Technology
Neal S Williams (Author) - Henrob (UK) Pty. Ltd, United Kingdom
Stuart E Blacket (Author) - Henrob (UK) Pty. Ltd, United Kingdom
Yvonne Durandet (Author) - Swinburne University of Technology
Publication details: Journal of Materials Processing Technology, Vol.223, pp.225-231
Publisher: Elsevier BV
Date published: 2015
DOI: 10.1016/j.jmatprotec.2015.04.006
ISSN: 0924-0136; 0924-0136
Organisation Unit: School of Science and Engineering - Legacy; University of the Sunshine Coast, Queensland; School of Science, Technology and Engineering
Language: English
Record Identifier: 99449912702621
Output Type: Journal article
Research Statement: false
