A flow cell for transient voltammetry and in situ grazing incidence X-ray diffraction characterization of electrocrystallized cadmium(II) tetracyanoquinodimethane

J P Veder; A Nafady; G Clarke; R P Williams; Roland De Marco; A M Bond

doi:10.1016/j.electacta.2010.09.106

$A flow cell for transient voltammetry and in situ grazing incidence X-ray diffraction characterization of electrocrystallized cadmium(II) tetracyanoquinodimethane$

Journal article

Peer reviewed

A flow cell for transient voltammetry and in situ grazing incidence X-ray diffraction characterization of electrocrystallized cadmium(II) tetracyanoquinodimethane

J P Veder, A Nafady, G Clarke, R P Williams, Roland De Marco and A M Bond

Electrochimica Acta, Vol.56(3), p.1546–1553

2011

DOI: https://doi.org/10.1016/j.electacta.2010.09.106

Files and links (1)

url

https://doi.org/10.1016/j.electacta.2010.09.106View

Published Version

Abstract

electrochemical surface and interface analysis

in situ external reflection X-ray analysis

synchrotron radiation-grazing incidence

X-ray diffraction

electrocrystallization

An easy to fabricate and versatile cell that can be used with a variety of electrochemical techniques, also meeting the stringent requirement for undertaking cyclic voltammetry under transient conditions in in situ electrocrystallization studies and total external reflection X-ray analysis, has been developed. Application is demonstrated through an in situ synchrotron radiation-grazing incidence X-ray diffraction (SR-GIXRD) characterization of electrocrystallized cadmium (II)-tetracyanoquinodimethane material, Cd(TCNQ)2, from acetonitrile (0.1 moldm-3 [NBu4][PF6]). Importantly, this versatile cell design makes SR-GIXRD suitable for almost any combination of total external reflection X-ray analysis (e.g., GIXRF and GIXRD) and electrochemical perturbation, also allowing its application in acidic, basic, aqueous, nonaqueous, low and high flow pressure conditions. Nevertheless, the cell design separates the functions of transient voltammetry and SR-GIXRD measurements, viz., voltammetry is performed at high flow rates with a substantially distended window to minimize the IR (Ohmic) drop of the electrolyte, while SRGIXRD is undertaken using stop-flow conditions with a very thin layer of electrolyte to minimize X-ray absorption and scattering by the solution.

Details

Title: A flow cell for transient voltammetry and in situ grazing incidence X-ray diffraction characterization of electrocrystallized cadmium(II) tetracyanoquinodimethane
Authors: J P Veder (Author) - Curtin University of Technology
A Nafady (Author) - Monash University
G Clarke (Author) - Curtin University of Technology
R P Williams (Author) - Curtin University of Technology
Roland De Marco (Author) - Curtin University of Technology
A M Bond (Author) - Curtin University of Technology
Publication details: Electrochimica Acta, Vol.56(3), p.1546–1553
Publisher: Pergamon
Date published: 2011
DOI: 10.1016/j.electacta.2010.09.106
ISSN: 0013-4686
Organisation Unit: University of the Sunshine Coast, Queensland; Office of the Deputy Vice-Chancellor (Research and Innovation)
Language: English
Record Identifier: 99449988202621
Output Type: Journal article
