Tip-induced nano-scale manipulation of Si and DLC surfaces: The state of the tip

S Myhra; Gregory S Watson

doi:10.1117/12.582649

Back

Tip-induced nano-scale manipulation of Si and DLC surfaces: The state of the tip

Conference paper

Peer reviewed

Tip-induced nano-scale manipulation of Si and DLC surfaces: The state of the tip

S Myhra and Gregory S Watson

Proceedings of SPIE - International Society for Optical Engineering, Vol.5650, pp.464-473

Micro- and Nanotechnology: Materials, Processes, Packaging, and Systems II, 2004 (Sydney, Australia, 13-Dec-2004–15-Dec-2004)

SPIE: International Society for Optical Engineering

2005

DOI: https://doi.org/10.1117/12.582649

Files and links (1)

url

https://doi.org/10.1117/12.582649View

Published Version

Abstract

atomic force microscopy

nano-writing

surface manipulation

surface oxidation

tunnelling

nano-machining

current voltage characteristics

diamond like carbon films

heat transfer

silicon

thermal conductivity

nanotechnology

Oxidative nano-writing by a conducting AFM tip to Si substrates has so far been ascribed to an anodic electrochemical process. However, there is evidence that thermal effects may play a role. More recently it has been demonstrated that conducting diamond-like carbon (DLC) films can be nano-machined by a biased conducting tip; the process is evidently due to local thermally activated oxidation and formation of CO 2 Thus the prevailing description in terms of an athermal anodic oxidative mechanism will need to be revisited and possibly revised. The physico-chemical state of the tip is known to affect the rate and efficiency of the process in some unspecified manner. It is plausible to ascribe variations in the I-V characteristics and thermal transport to tip effects that are operational at the point of contact. However, so far the focus has been on the surface, and little attention has been given to a detailed and relevant characterization of the tip and its efficacy as a manipulative probe. Tips were prepared with a range of known initial conditions (i.e. doped Si plus H-termination, Au-coating, or native oxide). I-V characteristics were correlated against oxidative efficiency versus clean H-terminated Si, Si plus native oxide, Si plus 2.5 nm thermal oxide and DLC. The outcomes at positive sample bias can variously be described by ohmic transport, by Fowler-Nordheim, and direct tunnelling. Likewise, tip alteration resulting from oxidative surface manipulation has been monitored by subsequent characterization. The evidence favours a thermal mechanism of oxidation arising from a repetitive, but interrupted, deposition of thermal energy at the tip-to-surface junction, where inelastic tunnelling completes the circuit. Thus there is a narrow temperature window of optimum conditions. The tip will deteriorate irreversibly if the peak temperature is too high, while oxidation of the surface will not take place if the peak temperature is too low.

Details

Title: Tip-induced nano-scale manipulation of Si and DLC surfaces: The state of the tip
Authors: S Myhra (Author) - Oxford University, United Kingdom
Gregory S Watson (Author) - Griffith University
Contributors: Jung-Chih Chiao (Editor)
David N Jamieson (Editor)
Lorenzo Faraone (Editor)
Andrew S Dzurak (Editor)
Publication details: Proceedings of SPIE - International Society for Optical Engineering, Vol.5650, pp.464-473
Conference details: Micro- and Nanotechnology: Materials, Processes, Packaging, and Systems II, 2004 (Sydney, Australia, 13-Dec-2004–15-Dec-2004)
Publisher: SPIE: International Society for Optical Engineering
Date published: 2005
DOI: 10.1117/12.582649
ISBN: 9780819456106
Organisation Unit: School of Science and Engineering - Legacy; University of the Sunshine Coast, Queensland; School of Science, Technology and Engineering
Language: English
Record Identifier: 99449278702621
Output Type: Conference paper
