Conference paper
Effect of Load Cycling on High Temperature Creep of 316L Stainless Steel
Proceedings of the 29th SolarPACES International Conference (SolarPACES 2023), Volume 2, pp.1-8
SolarPACES: International Conference on Concentrating Solar Power and Chemical Energy Systems, 29th (Sydney, Australia, 10-Oct-2023–13-Oct-2023)
TIB Open Publishing
2024
Abstract
For components in concentrating solar thermal plants, the creep mechanism will cause a significant portion of material damage to receivers, storage tanks, turbines and pipework. These components will undergo conditions where loads, temperature, or both load and temperature are not constatnly applied. This creep damage process will not resemble the constant load creep tests used to characterise creep of materials. Therefore, creep tests incorporating a load cycle were undertaken to obtain a better understanding of how high temperature materials respond to these cyclic conditions. These tests showed that when time under load was considered, creep undertaken under load cycling conditions were accelerated relative to constant load conditions. A modified Larson-Miller approach was used to assess this effect and determine an equivalent stress where constant load test data agrees with the cycled test data. This found that cycling the load was equivalent to if the system were under 3 and 7 MPa higher stress, for tests which were loaded for 12 hrs and 6 hrs per 24 hrs respectively. This could be a potential approach to simply and easily consider these load cycling effects for design and life analysis.
Details
- Title
- Effect of Load Cycling on High Temperature Creep of 316L Stainless Steel
- Authors
- Stuart Bell (Author) - Queensland University of TechnologyRichard Clegg (Author) - Queensland University of TechnologyMichael Cholette (Author) - Queensland University of TechnologyHuy Truong-Ba (Author) - Queensland University of TechnologyGeoffrey Will (Author) - University of the Sunshine Coast, Queensland, School of Science, Technology and EngineeringTed Steinberg (Author) - Queensland University of Technology
- Publication details
- Proceedings of the 29th SolarPACES International Conference (SolarPACES 2023), Volume 2, pp.1-8
- Conference details
- SolarPACES: International Conference on Concentrating Solar Power and Chemical Energy Systems, 29th (Sydney, Australia, 10-Oct-2023–13-Oct-2023)
- Publisher
- TIB Open Publishing
- Date published
- 2024
- DOI
- 10.52825/solarpaces.v2i.901
- ISSN
- 2751-9899
- Copyright note
- Copyright (c) 2024 Stuart Bell, Richard Clegg, Michael Cholette, Huy Truong-Ba, Geoffrey Will, Ted Steinberg. This work is licensed under a Creative Commons Attribution 4.0 International License.
- Data Availability
- Data utilised to acquire the results in this study will be made available upon reasonable request.
- Grant note
- This research was performed as part of the Australian Solar Thermal Research Initiative (ASTRI), a project supported by the Australian Government, through the Australian Renewable Energy Agency (ARENA).
- Organisation Unit
- School of Science, Technology and Engineering
- Language
- English
- Record Identifier
- 991062294702621
- Output Type
- Conference paper
